Laser Cutting

Tube Laser Cutting - FL170

Photo of a BySprint Fiber laser cutter

The Fibre Laser for fast and versitile applications

Concentrated technology: The cutting system combines the unique benefits of fiber laser technology with the versatility of 3D cutting.
We cut steel, stainless steel, aluminum, and non-ferrous metals in diameters from 12.7 to 168.3 mm wide range of applications and industries.

* Bundle loading of up to 8m lengths for efficient material handling.
* Bevels and angle cuts of up to 45 degrees, in addition to straight cut edges
* This versatility eliminates the need for costly milling,  drilling, punching, or sawing processes.

FL170 close up
FL170 Loader
Autobend's FL170 Tube Laser

Flat Bed Laser Cutting

Now Cutting in Auckland and Christchurch

Photo of a BySprint Fiber laser cutter

Laser cutting is extremely accurate (+/- 0.2mm) for cutting mild steel, stainless, aluminum and other non-ferrous materials.

With the option of our Bystronic BySprint and BySmart 6Kw fiber or our Trumpf L3030 4Kw CO2 lasers we have all the bases covered allowing us to produce a cost effective, high quality finish.

Efficient "nesting" combined with "Detection Eye" technology plus our 3000mm × 1500mm Bytrans Extended automated sheet loading system minimizes down time for one-offs or runs of 1000 pieces.

We accept 2D or 3D CAD files for “flat bed” cutting of sheet or “rotolas” cutting of round, square or rectangular material.
Email us for a quote

  • Mild Steel up to 25 mm

  • Stainless up to 30 mm

    Aluminium up to 30 mm

    Copper up to 12 mm

  • Brass up to 15 mm

Our Bysoft 7 software will take your 3D model, flatten it out, process it for laser cutting and folding to your specifications -
all at the click of the mouse...
Bystronic Doors
Bysoft
Sheet Skeleton
